GU-3900B series “General Function” Software Specification
4.7.4.5
US ( w 10h a
(Write screen mode select)
Code:
1Fh 28h 77h 10h a
a:
Write screen mode
a = 00h: Display screen mode
a = 01h: All screen mode
Definable area:
00h ≤ a ≤ 01h
Default:
a = 00h or Memory SW setting.
Function:
Select the write screen mode. This setting is only applicable for Base-Window.
Display screen mode: Display action is valid within area of either Display area or Hidden area,
depending on cursor position.
All screen mode: Display action is valid over the entire display memory.
4.7.4.6
ESC R n
(International font set)
Code:
1Bh 52h n
Definable area:
00h ≤ n ≤ 0Dh
Default:
n = 00h or Memory SW setting.
Function:
Select international font set.
Characters already displayed are not affected.
- 26
-
n
Font set
00h
America
01h
France
02h
Germany
03h
England
04h
Denmark 1
05h
Sweden
06h
Italy
07h
Spain1
08h
Japan
09h
Norway
0Ah
Denmark2
0Bh
Spain2
0Ch
Latin America
0Dh
Korea
Display memory
8 dots
1 dot
Cursor position
